Rulo Sac
SICAK HADDELENMİŞ RULO
- Commercial
- API*
- HSLA
- Structural
- Pressure Vessel
- Corten Steel
- Chequered steel
API 5L Grade can be produced to cover both sour and non-sour applications::
Non-Sour |
Gr. B, X42, X46, X52, X56, X60, X65, X70, X80 |
Sour |
Gr. B, X42, X46, X52, X60, X65 |
Mevcut Çap / Boyutlar
Non- Pickled |
Thickness (mm) |
Width (mm) |
Inner Dia (mm) |
From |
To |
From |
To |
Hot Rolled Coil Mill Edge |
1.2 |
17.5 |
850 |
1650 |
762 |
Hot Rolled Coil Non Skin Pass |
4 |
6 |
850 |
1650 |
610 |
Hot Rolled Coil Trim Edge |
1.5 |
8 |
850 |
1600 |
762 |
Hot Rolled Slit Coil |
1.5 |
8 |
75 |
800 |
762 |
Pickled |
Thickness (mm) |
Width (mm) |
Inner Dia (mm) |
From |
To |
From |
To |
Hot Rolled Coil |
1.5 |
6 |
850 |
1650 |
762 |
Hot Rolled Trimmed Coil |
1.5 |
6 |
820 |
1600 |
762 |
Others |
Thickness (mm) |
Width (mm) |
Inner Dia (mm) |
From |
To |
From |
To |
Hot Rolled Skin Pass Coil |
1.2 |
4 |
850 |
1600 |
762/610 |
Hot Rolled Chequered Coil |
1.6 |
8 |
850 |
1500 |
762 |
SOĞUK HADDELENMİŞ RULO
Özellikler
Full Hard
High hardness, low tensile strength and ductility.
Annealed
As cold rolled full hard coils are not suitable for most applications due to high hardness, ultimate tensile strength and low ductility, the coils are annealed to the recrystallization temperature in the Batch Annealing Facility (BAF) to improve the workability for various applications.
Tempered (Skinpass)
The surface roughness of Cold Rolled Coils and Cold Rolled Slit Coils is controlled by tempering.
DIMENSIONS / SIZES
Product |
Thickness (mm) |
Width (mm) |
Inner Dia. (mm) |
Outer Dia. (mm) |
Cold Rolled Coils |
0.3 - 3 |
850-1650 |
610 |
1950 |
Cold Rolled Slit Coils |
0.3 - 3 |
75/800 |
610 |
1950 |
